Sudco Vol 38

479 / 612

Nology Hot Wires
Hot Wires are engineered with a unique built-in capacitor that allows
energy from the ignition coil to accumulate (stored) until the voltage can
be released as an ultra-short, ultra-hot spark. Combustion is faster and
more complete, resulting in increased horsepower and a more complete
burn. Hot Wires are compatible with all aftermarket or stock ignition
systems. Electronic ignitions are preferred but satisfactory results are
achieved with point ignition when the points and condenser are in
perfect working order. Each Hot Wire includes a 23” or 30”
black silicone Hot Wire with grounding strap, 90 degree or 180 degree
(straight) spark plug cap, in-line wire connector and heat shrink tubing.
Sold each. Note: Requires non-resistor spark plugs.
Nology Pro Fire Compact Ignition Coils
Pro Fire ignition coils utilize advanced technology to supply the energy
needed for trouble-free high performance and high rpm operation.
They are designed to have the quickest rise time along with substantial
energy reserves. Spark voltage is in excess of 45,000 volts over the
entire rpm range. Pro Fire coils come in single or dual high tension
towers and are available in 0.3 ohm, 0.6 ohm, 1.5 ohm and 3.0 ohm.
Coil connectors and boot are included. Sold each.
Note: To determine which Nology ignition coil to use,
measure the primary winding resistance of your stock ignition coil.
Round down to the nearest whole ohm.
0.5 ohm and 0.6 ohm primary resistance ignition coils are for C.D.I. type
ignitions found on late model ATV, Dual Sport, MX. and Offroad.
Note: Do not use Nology Ignition Coils on point type ignitions or on
the following models: Honda VFR, CB, CBX; Kawasaki ZX10, GPZ,
KZ1000J, Z1-900; Suzuki GSXR (early oil cooled), GS;
Yamaha FJ1100/1200 and VMX12 V-Max.
Description Nology No. Order No.
90 Degree Plug Boot HW-MC-90-23B 618-600
90 Degree Plug Boot (use with Karts) HW-GK-90-23 618-610
180 Degree Plug Boot HW-MC-180-23B 618-601
23” Length Hot Wires, 7mm
30” Length Hot Wires, 7mm
Description Nology No. Order No.
90 Degree Plug Boot HW-MC-90-30B 618-602
180 Degree Plug Boot HW-MC-180-30B 618-603
Description Ohms Nology No. Order No.
Single Secondary outlet 3.0 primary PFC-30-S 618-510
0.6 primary (C.D.I.) PFC-06-S 618-512
0.3 primary (C.D.I.) PFC-03-S 618-514
Dual Secondary outlet 3.0 primary PFC-30-D 618-511
0.6 primary (C.D.I.) PFC-06-D 618-513
0.3 primary (C.D.I.) PFC-03-D 618-515
Nology Hot Wires - Model Specific Applications
Available in kits for applications listed.
Ducati
Honda
Suzuki
Yamaha
WR400F/YZ400F(S.O.T.) 1999 Red 012 131 001 618-469
FZ750 85-88 Black 012 134 002 618-471
FZR750RT/RU 87-88 Black 012 134 002 618-471
VF750C V45 Magna 82-83 Black 012 064 302 618-449
VF750F V45 Interceptor 83-84 Black 012 064 302 618-449
VF750S V45 Sabre 82-83 Black 012 064 302 618-449
VFR1000F Interceptor 1984 Black 012 064 302 618-449
VFR1000R 85-86 Black 012 064 302 618-449
VF1100C V65 Magna 83-86 Black 012 064 302 618-449
VF1100S V65 Sabre 82-83 Black 012 064 302 618-449
SV650X/Y/K1/K2 99-02 Red 012 112 021 618-462
SV650SX/SY/SK1/SK2 99-02 Red 012 112 021 618-462
Dyna Ignition Coil Kits for Yamaha
These high tech ignition coils for Yamaha models listed provide
maximum performance, producing spark voltage in excess of 30,000
volts. Sold as a kit.
Model Year Dyna No. Order No.
YXR450 Rhino Side x Side 06-07 DCK7-2 618-769
YXR660 Rhino Side x Side 04-07 DCK7-2 618-769
XVS1100 V-Star 1100 05-08 DCK7-7 618-770
Model Year Color Nology No. Order No.
851 Strada 89-02 Red 012 042 401 618-439
916 93-98 Red 012 042 401 618-439
996 98-01 Red 012 042 401 618-439
618-769
Yamaha
Ignition Products
471
