APE Manual Cam Chain Tensioners for Vintage Applications
A Must for any kind of performance riding. APE manual cam chain tensioner are CNC machined
from billet alloy to exact tolerances for perfect fit. Designed to replace the automatic and hydraulic
tensioner on high performance engines. The automatic adjusters can back out when the throttle is
suddenly closed at high rpm. This allows the cams to go momentarily out
of time and can result in bent valves and/or serious engine damage. Hydraulic tensioner have a
tendency to put too much tension on the chain guide under high rpm/high oil pressure conditions
resulting in premature wear. Both problems can be eliminated with the installation of the APE
manual cam chain tensioner. No matter what the engine does, the cam chain tensioner will remain
constant. Cam Chain Tensioner are sold each.
Cam Chain Tensioner
C am Chain Tensioner Gasket
Model Year APE No. Order No. Cometic No. Order No.
EX500 87-08 KT1050 875-415 ––––––––– –––––––
ZX600A Ninja 600R 85-87 KT1100 875-416 comes with o-ring –––––––
VN750A Vulcan 750 (*qt2 required) 86-03 KT1100 875-416* comes with o-ring –––––––
KZ900A4/A5 76-77 KT1000 875-418 EC067 875-782
KZ900B1 LTD 1976 KT1000 875-418 EC067 875-782
Z1/A/B-900 73-75 KT1000 875-418 EC067 875-782
ZX900A Ninja 900R 84-86 KT1050 875-415 –––––––– ––––––––
KZ1000A1/A2/A2A 77-78 KT1000 875-418 EC067 875-782
KZ1000A3/A3A/A4 MKII 79-80 KT1000 875-418 EC067 875-782
KZ1000B1/B2/B3/ B4 LTD 77-80 KT1000 875-418 EC067 875-782
KZ1000C1/C1A/C2/C3/C4 Police 78-81 KT1000 875-418 EC067 875-782
KZ1000D1 Z1R 1978 KT1000 875-418 EC067 875-782
KZ1000D3 Z1R 1980 KT1000 875-418 EC067 875-782
KZ1000E1/E2 Shaft ST 79-80 KT1000 875-418 EC067 875-782
KZ1000J 81-83 KT1100 875-416 comes with o-ring ––––––––
Suzuki Street
GSX-R750 oil cooled 86-92 ST750 875-402 EC065 875-781
GS1100/1150 all ST1100 875-404 EC062 875-789
GSX-R1100 oil cooled 87-92 ST750 875-402 EC065 875-781
Yamaha Street
FJ1100 84-85 YT1000 875-435 EC019 875-780
FJ1200 86-93 YT1000 875-435 EC019 875-780
APE Kawasaki Cam Chain Idler Adapter
This adapter allows the use of later model GPz 1100 or KZ1000J
cylinder head on earlier model KZ900/KZ1000 lower end. It maintains
the roller style cam chain. This is the only modification necessary to
install the big valve head on early motor. Use with OEM KZ sprockets
or high performance aftermarket versions.
Description APE No. Order No.
Cam Chain Idler Adapter with Pin CCIA 875-450
