Sudco Vol 38

309 / 612

Sudco Part Number to OEM Cross Reference
Exhaust Pipe Gaskets
Honda
Sudco Part Number to OEM Cross Reference
Exhaust Pipe Gaskets
OEM Reference Dimensions Vesrah Order No.
I.D. x O.D. x Thickness Reference
18291-KK0-003 30.00 x 37.80 x 4.0mm VE-1031 503-131
18291-KZ1-670 30.00 x 37.80 x 4.0mm VE-1031 503-131
18291-MN4-920 34.80 x 43.00 x 4.0mm VE-1008 503-108
18291-MN5-650 31.50 x 39.80 x 4.0mm VE-1003 503-103
18291-MM5-860 37.00 x 45.10 x 4.0mm VE-1005 503-105
18291-MM8-880 44.20 x 52.00 x 4.0mm VE-1012 503-112
18291-MR5-801 44.20 x 52.00 x 4.0mm VE-1012 503-112
18291-MV9-000 34.80 x 43.00 x 4.0mm VE-1008 503-108
18291-028-306 32.00 x 38.00 x 3.5mm VE-1002 503-102
18291-283-000 44.20 x 52.00 x 4.0mm VE-1012 503-112
18291-286-306 VE-1006 503-106
Suzuki
14181-37D00 VE-3001 503-301
14172-02B40 VE-3027 503-327
14181-01D00 38.00 x 46.60 x 5.0mm VE-3003 503-303
14181-05020 32.00 x 42.00 x 5.0mm VE-3002 503-302
14181-05010 32.00 x 42.00 x 5.0mm VE-3002 503-302
14181-11010 38.00 x 46.60 x 5.0mm VE-3003 503-303
14181-11020 38.00 x 46.60 x 5.0mm VE-3003 503-303
14181-12010 VE-3004 503-304
14181-17C00 32.00 x 42.00 x 5.0mm VE-3002 503-302
14181-17E00 28.70 x 42.00 x 2.50mm VE-3024 503-324
14181-18C00 32.00 x 42 x 5.5mm VE-3022 503-322
14181-23E00 29.40 x 38.80 x 5.0mm VE-3026 503-326
14181-42A00 VE-3004 503-304
14181-45C00 VE-3019 503-319
14181-38A00 VE-3019 503-319
14181-40C00 35.20 x 41.75 x 3.00mm VE-3023 503-323
14181-46E00 33.30 x 42.00 x 5.00mm VE-3025 503-325
14181-45D00 29.40 x 38.80 x 5.0mm VE-3026 503-326
14181-42A00 34.20 x 43.20 x 5.0mm VE-3028 503-328
14172-27C30 VE-3029 503-329
14172-28C30 40.40 x 49.50 x 1.0mm VE-3030 503-330
Yamaha
OEM Reference Dimensions Vesrah Order No.
I.D. x O.D. x Thickness Reference
3MT-14613-00-00 VE-2001 503-201
3RV-14623-00-00 –––––––
132-14613-00-00 –––––––
3PA-14613-10-00 VE-2002 503-202
3PA-14613-00-00 –––––––
152-14613-00-00 –––––––
4BE-14613-00-00 38.20 x 45.60 x 4.8mm VE-2004 503-204
4TR-14613-00-00 38.20 x 45.60 x 4.8mm –––––––
341-14613-00-00 38.20 x 45.60 x 4.8mm –––––––
2GV-14613-00 38.20 x 45.60 x 4.8mm –––––––
90430-38054 39.10 x 49.00 x 4.8mm VE-2005 503-205
4X4-14623-10-00 VE-2010 503-210
4X4-14613-00-00 VE-2010 503-210
4X7-14613-00-00 VE-2011 503-211
4H7-14613-00-00 30.10 x 39.00 x 3.2mm VE-2012 503-212
3R4-14613-00-00 VE-2014 503-214
5Y1-14613-00-00 32.00 x 40.50 x 3.0mm VE-2018 503-218
2GU-14613-10-00 56.60 x 80.30 x 5.0mm VE-2023 503-223
3DM-14613-00-00 VE-2024 503-224
22F-14613-00-00 –––––––
3GD-14613-00-00 38.50 x 49.50 x 5.0mm VE-2025 503-225
3YF-14613-01-00 32.00 x 42.00 x 3.0mm VE-2026 503-226
4BR-14613-00-00 30.50 x 39.10 x 5.0mm VE-2027 503-227
3EG-14613-00-00 42.52 x 55.36 x 3.40mm VE-2028 503-228
4FM-14613-00-00 37.20 x 44.75 x 3.50mm VE-2029 503-229
Kawasaki
18067-004 32.70 x 39.00 x 3.0mm VE-4002 503-402
18067-008 VE-4003 503-403
18067-018 34.80 x 43.00 x 4.1mm VE-4005 503-405
18067-020 34.5 x 45.0 x 5.0mm VE-4006 503-406
11009-1253 VE-4008 503-408
11009-1374 VE-4013 503-413
11009-1380 VE-4007 –––––––
11009-1840 VE-4004 503-404
11009-1866 32.70 x 39.00 x 3.0mm VE-4002 503-402
11009-1906 34.80 x 43.00 x 4.1mm VE-4005 503-405
11009-1949 VE-4008 503-408
11060-1108 50.90 x 60.10 x VE-4013 503-413
11060-1242 34.5 x 45.0 x 5.0mm VE-4006 503-406
11060-1488 VE-4007 –––––––
11060-1496 39.30 x 45.60 x 2.40mm VE-4003 503-403
11060-1764 41.50 x 49.40 x 4.1mm VE-4012 503-412
11061-S058 VE-3026 503-326
503-204 503-325 503-403 503-105
Note: 503-223 is a muffler gasket, not an exhaust pipe gasket.
Exhaust Pipe Gaskets
301
