CR Special (CRS) Replacement Parts
Applications: CR26, CR29, CR31, CR33, CR35, CR37, CR39.
Keihin Part No. highlighted in BOLD RED are included in rebuild kit.
No.Description Application Keihin No. Order No.
1. Rubber Cap 26-33mm R028-004-7000 018-811
35-39mm 1028-809-7000 018-810
2. Velocity Stack 45mm 26-33mm 1130-800-2001 020-220
Velocity Stack 70mm 26-33mm 1130-801-2001 020-222
Velocity Stack 45mm 35-39mm 1130-802-2001 020-244
3. Clamps 26-33mm 1129-803-7000 018-798
35-39mm 1129-804-7000 018-799
4. Mounting Adapters (Spigots) Pg.126-127
5. O-Ring 26-33mm 0901-812-6000 018-600
35-39mm 0901-012-6000 018-601
6. Tension Spring 26-39mm 1291-804-2000 018-604
7. Tube 26-39mm 0840-846-0000 018-606
8. Collar 26-39mm 1118-878-2000 018-608
9. Screw 26-39mm 4139-802-1100 018-610
10. Top Cap 26-39mm 1030-814-2002 018-612
11. Gasket, Top Cap 26-39mm 1031-802-2002 018-614
12. Jet Needle (see page 53 for * optional Jet Needles)
5 Clip position 26-33mm N427-11Y-xxx Pg.131
7 Clip position 26-33mm N427-12Y-xxx Pg.131
5 Clip position 35-39mm N427-38-xxx Pg.131
7 Clip position 35-39mm N427-51-xxx Pg.131
13. Clip 26-39mm 0403-802-1000 018-616
14. Locknut 26-39mm 0208-803-1200 018-618
15. Stop Screw 26-39mm 1034-814-2000 018-620
16. Screw 26-39mm W9155-04060 018-622
17. Valve Plate 26-33mm 1019-802-2101 018-624
35-39mm 1019-801-2101 018-625
18. Clip 26-39mm W9302-3000 018-626
16179-676-3000
19. Plain Washer 26-39mm 0301-825-7000 018-628
20. Link Arm 26-39mm 1061-805-2000 018-630
21. Spring 26-39mm 1291-802-2000 018-632
22. Throttle Valve 26-33mm N502-04x-00 Pg.129
35-39mm N502-03x-00 Pg.129
23. Float Bowl 26-39mm 1050-825-2000 018-660
24. Drain Bolt 26-39mm 1018-801-2000 018-662
25. O-Ring 26-39mm 16173-001-0040 018-664
26. Starter Jet 26-39mm 1001-108-xxx Pg.149
27. O-Ring 26-39mm 0901-811-6000 018-668
28. Arm Pin 26-39mm W9525-25250 018-670
29. Float 26-39mm 1052-818-2100 018-672
30. Clip 26-39mm 0405-019-1000 018-674
31. Needle Valve 26-39mm 16155-ZG8-L100 018-676
32. Screw 26-39mm W9155-04060 018-622
33. Plate 26-39mm 1164-038-2000 018-678
34. Valve Seat (Std) 26-39mm N360-01L00-3.2 018-690
Valve Seat (*Optional) 26-39mm N360-01x00 Pg.128
35. O-Ring, Valve Seat 26-39mm 16075-MB0-0030018-694
36. Main Air Jet 26-39mm N424-14-xxx Pg.151
37. Slow Jet 26-39mm N424-24-xxx Pg.148
38. Main Jet 26-39mm 99101-357-xxx Pg.150
39. Nozzle Holder 26-39mm N426-04000 018-696
40. Screw 26-39mm 4115-800-1101 018-698
41. Jet Block 26-39mm 1605-xxx-2001 Pg.130
42. Gasket 26-33mm 1202-809-2002 018-710
35-39mm 1202-808-2002 018-712
43. Nozzle, Flat Type 26-39mm 1041-800-2000 018-714
Nozzle, Screen Type 26-39mm 1041-801-2000 018-715
Nozzle Screen Type-Used for drag racing and alcohol conversions.
44. Air Screw 26-39mm 1014-004-2002 018-718
45. Spring 26-39mm 1290-003-2001 018-720
46. O-Ring 26-39mm 0901-006-6000 018-722
47. Screw 26-39mm 4110-806-1100 018-724
48. Nut 26-39mm 0205-800-1100 018-726
49. Bolt 26-39mm 0118-801-1100 018-728
See page 128 for CR Special Carburetor Kits and
Methanol Conversion Kits.
CR Special Parts
No.Description Application Keihin No. Order No.
50. Plain Washer 26-39mm 0301-009-1100 018-730
51. Wave Washer 26-39mm 2007-800-2000 018-732
52. Plain Washer 26-39mm 0301-104-7000 018-734
53. Clip 26-39mm W9302-25000 018-736
54. Collar 26-39mm 1118-801-2000 018-738
55. Shaft 26-39mm 1111-813-2000 018-740
56. Lever 26-39mm 1113-861-2001 018-742
57. Lever 26-39mm 1113-862-2000 018-744
58. Screw 26-39mm 4139-804-1100 018-746
59. Bracket, Top/Bottom 26-39mm 1190-833-2000 018-748
60. T-Joint 26-39mm 1077-804-7000 018-751
61. T-Joint 26-39mm 1077-803-7000 018-753
26-39mm Single Outlet 021-853
62. O-Ring 26-39mm W9351-13057 018-755
63. Screw 26-39mm W9155-04060 018-622
64. Bracket 26-39mm 1190-832-2000 018-757
64A. Bracket (Closer) 26-39mm 1190-869-2000 021-852
65. Rubber Cap 26-39mm 1028-808-7000 018-759
66. Clip 26-39mm W9535-55000 018-761
67. Link Lever 26-39mm 1100-836-2100 018-763
68. Collar 26-39mm 1118-861-7000 018-765
69. Collar 26-39mm 1118-860-7000 018-767
70. Spring 26-39mm 1305-883-2000 018-769
71. Throttle Shaft 4-cyl. 26-39mm 5025-847-2200 018-771
71A.Throttle Shaft 2-cyl. 5025-891-2101 021-556
72. Screw 26-39mm 4139-803-1100 018-773
73. Bracket 26-39mm 1190-831-2002 018-775
74. Idle Speed Screw 26-39mm 1034-808-2000 018-777
(Stop Screw)
74A. Idle Speed Screw* 26-39mm 1034-902-2100 018-778
(Stop Screw) *Option
75. Spring 26-39mm 1290-849-2003 018-779
76. Plain Washer 26-39mm 16178-ML7-0040 018-781
W9201-05100 (old number)
77. Nut 26-39mm 94001-0508-0S 018-783
78. Screw 26-39mm 93500-05025-1H 018-785
79. Rubber Cap 26-39mm 1028-042-7001 018-787
80. Cap 26-39mm 1029-805-7000 018-789
81. Spring 26-39mm 1300-136-2000 018-791
82. Starter Valve 26-39mm 1166-802-2101 018-793
83. Seal 26-39mm 1099-805-7000 018-795
84. L-Joint 26-39mm 1074-817-7001 018-797
85. Air Leak Jet 26-39mm 1001-108-xxx Pg.150
86. End Cap 26-39mm 1096-810-2000 018-796
