Size (mm)
A
B
C
D
Total Width
TMX38-2
46
75
152.5 62
86
TMX38-5
46
70
152.5 62
86
Carb
Main
Pilot
Needle
Jet
Throttle Valve Needle
Float Mikuni Order
Size
Jet
Jet
Jet
Needle
Cutaway
Valve Set
Height No.
No
TMX38
4/042 #310
N224.103 #20 6BEG18-68 832-42016-5.0 832-42016
786-36011-3.8 6-7mm TMX38-2
–––––––
TMX38
4/042 #640
N224.103 #30 6BEG2-60 832-42016-5.0 832-42016
786-26004-1.5 6-7mm TMX38-5
–––––––
Mikuni TMX Series Carburetors are intended for off-road
riding and racing use only. Not legal for use in California
or other locations where similar pollution laws may apply.
Float Height
6 - 7mm
TMX Series (Late Style) Exploded View
Carburetor Dimensions
A
D
C
TMX Oval Slide Carburetors (Late Style) Standard Jetting
